Echo CS-2511T Owner's/Operator's Manual

32
CS-2511T
• Place the depth gauge tool rmly on guide bar
so that depth gauge protrudes.
Then le top of depth gauge with the at le until
at with top of the depth gauge tool.
- Be sure to round o the front edge of the
depth gauge.
Properly led cutters are shown in illustration.
When setting of the chain is nished, soak it in oil
and wash away lings completely before using.
- When chain has been led on the bar,
supply sucient oil to it, rotate the chain
slowly to wash away the lings before using
again.
- If the chain saw is operated with lings
clogged in the groove, the saw chain and the
guide bar will be damaged prematurely.
- If the saw chain becomes soiled with resin, for
instance, clean it with kerosene and soak in it
oil.
NOTICE
These angles are referred to as Oregon 91PXL
or 90PX.
To sharpen other follow chain manufacturer’s
instruction.
Remove until
at with tool
Depth gauge tool
Round o the edge
1/5
One fth of le diameter remains
above cutter edge
Top plate ling angle
30°
Parallel
0.65 mm
(0.025 in.)
Top plate cutting angle
Depth gauge
55°

Echo CS-2511T Specifications

General

Engine Displacement	25.0 cc
Fuel Tank Capacity	190 ml
Oil Tank Capacity	140 ml
Weight (without bar and chain)	2.3 kg
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Bar Length	12 in
Fuel Capacity	190 ml
Oil Capacity	140 ml
Guide Bar Length	12 in
