OPERATION CS-2511T
40 X7503332503
© 11/19 ECHO Incorporated
Guide Bar
(Low-kickback)
Replacement guide bars.
The following guide bars may be considered to have equivalent kickback
energy.
• Sprocket nose guide bars of the same length and nose radius, same pitch
and having the same number of teeth.
• Hard nose guide bars of the same length and nose radius as a sprocket
nose bar.
Saw Chain
(Low-kickback)
Do not use replacement saw chain unless it has been
designated as meeting ANSI B175.1 or CSA Z62.1, .3 kickback
performance requirements, when tested on the representative
sample of chain saws below 3.8 c.i.d. specified in ANSI B175.1
or CSA Z62.1, .3.
Note: LOW KICKBACK SAW CHAIN meets the kickback
performance requirements of ANSI B175.1 or CSA Z62.1, .3
(safety requirements for gasoline-powered chain saws).
Optional Kick Guards
TM
:
2894902 for ECHO models CS-271- CS-400
2893202 for ECHO models CS-450 - CS-800P
2894902 for Shindaiwa models 305s, 340s, 358TS, 402s
2893202 for Shindaiwa models 491s, 591, 600SX.

Echo CS-2511T Specifications

General

Engine Displacement	25.0 cc
Fuel Tank Capacity	190 ml
Oil Tank Capacity	140 ml
Weight (without bar and chain)	2.3 kg
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Bar Length	12 in
Fuel Capacity	190 ml
Oil Capacity	140 ml
Guide Bar Length	12 in
