Echo CS-2511T User Manual

OPERATION CS-2511T
30 X7503332503
© 11/19 ECHO Incorporated
Operation of this equipment may create sparks that can start
fires around dry vegetation. This unit is equipped with a spark
arrestor to prevent discharge of hot particles from the engine.
Metal cutters can also create sparks if the cutter strikes rocks,
metal, or other hard objects. Contact local fire authorities for
laws or regulations regarding fire prevention requirements.
Starting Cold Engine
Make sure the bar and chain are free from any obstruction when
starting the chain saw.
1. Move chain brake lever fully
FORWARD to LOCK chain brake
before starting.
2. Fill the fuel tank with fuel mixture.
Do not over fill.
3. Fill the chain oil tank with
lubricant. Do not over fill.
4. Move ignition switch FORWARD
to “RUN” position.
5. Push purge pump 3 to 4 times or
until fuel is visible in purge pump.
6. Turn choke control knob
counterclockwise to (CLOSED
[ ] choke position).
Chain Brake LOCKED
Shown with optional
Kick Guard
TM
START / RUN
Ignition Switch
Purge Pump
Choke Control Knob

Echo CS-2511T Specifications

General

Engine Displacement	25.0 cc
Fuel Tank Capacity	190 ml
Oil Tank Capacity	140 ml
Weight (without bar and chain)	2.3 kg
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Bar Length	12 in
Fuel Capacity	190 ml
Oil Capacity	140 ml
Guide Bar Length	12 in
