CLUTCH SYSTEM
CS-271T
36
5 CLUTCH SYSTEM
( A ) Clutch assembly
( B ) Clutch plate
( C ) Clutch drum
( D ) Needle bearing
( E ) Collar
( F ) Worm gear
( G ) Circular washer
( H ) Clutch hub
( J ) Clutch shoe
( K ) Clutch spring
(J)
(K)
(E)
(D)
(C)
(B)
(A)
(G)
(F)
(H)

Table of Contents

Other manuals for Echo CS-271T

Preview: Instruction Manual
Instruction Manual36 pages
Preview: Operator's Manual
Operator's Manual36 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo CS-271T and is the answer not in the manual?

Echo CS-271T Specifications

General IconGeneral
Engine Displacement26.9 cc
Bar Length12 inches
Chain Pitch3/8 inch
Fuel Capacity0.21 L
Chain Oil TypeBar and chain oil
Chain Gauge0.050 inch
Oil Capacity160 ml
