CHAIN BRAKE SYSTEM
CS-271T
39
6 CHAIN BRAKE SYSTEM
( A ) Brake lever
( B ) Collar
( C ) Spacer
( D ) Sprocket guard
( E ) Compression spring
( F ) Spacer
( G ) Brake band
( H ) Pin
( J ) Brake cover
( K ) Torsion spring
( L ) Brake connector
( M ) Spacer
(G)
(E)
(F)
(D)
(C)
(A)
(H)
(K)
(J)
(B)
(L)
(M)
