Echo CS-330T User Manual

33
tecHnIcAl DAtA
* Technical data subject to change without notice.
IMPORTANT
This spark ignition system complies with the Canadian standard ICES-002.
Model ............................................................................................. CS-330T
Dimension L x W x H ..................................................................... 277 x 247 x 214 mm (10.9 x 9.7 x 8.4 inch)
Weight Power head, dry ................................................................ 3.6 kg (7.9 lb) Without chain and guide bar
Engine .................................................... Type .............................. Air-cooled, two-stroke, single cylinder
................................................................ Displacement ................ 32.6 cc (1.989 cu.in.)
................................................................ Carburetor ..................... Diaphragm type
................................................................ Magneto ........................ Flywheel magneto : CDI system
................................................................ Spark Plug .................... NGK BPMR-8Y
................................................................ Starter ........................... Recoil starter
................................................................ Power transmission ...... Automatic centrifugal clutch
Fuel......................................................... Mixture ratio .................. 50 : 1 Power Blend X
TM
ISO-L-EGD (ISO/CD 13738)
....................................................................................................... and J.A.S.O. M345- FD, two-stroke, air-cooled
....................................................................................................... engine oil.
................................................................ Gasoline ........................ Use 89 Octane unleaded. Do not use fuel containing
....................................................................................................... methyl alcohol, more than 10% ethyl alcohol or 15%
....................................................................................................... MTBE. Do not use alternative fuels such as E-15 or
....................................................................................................... E-85.
......................................................Tank Capacity ............... 310 ml (10.5  oz U.S.)
Oil .................................................................................................. Power Blend X
TM
Premium Universal 2-Stroke Oil
................................................................ Bar and chain ................ ECHO bar and chain oil (or motor oil)
................................................................ Tank Capacity ............... 290 ml (9.8 . oz. U.S.)
................................................................ Lubrication .................... Adjustable automatic oil pump
Guide bar / Saw chain ............................ Standard ....................... 14 in
Optional ........................ 12, 16in
Standard features .......................................................................... Top Handle
....................................................................................................... Front hand guard,
....................................................................................................... Anti-vibration device,
....................................................................................................... Throttle control lockout,
....................................................................................................... Chain catcher,
Spark arrestor catalytic mufer
Idle Speed .................................................................................... 2,600 RPM
Clutch Engagement ....................................................................... 4,300 RPM
Wide Open Throttle (WOT) ............................................................ 13,500 RPM
Kickback Safety Features ............................................................. Double Guard Low Kick Guide Bar
....................................................................................................... Low Kick Guard Link Saw Chain
....................................................................................................... Front Hand Guard/Chain Brake Lever
....................................................................................................... Chain Brake
....................................................................................................... Kick Guard
