Echo CS-800P - Component Maintenance Procedures

25
CS-800P
Oil filter
Fuel filter
Oil tank cap
Fuel tank cap
0.65 mm (0.026 in.)
Cleaner cover knob
Air filter
Air cleaner cover
AIR FILTER
s #HECKBEFOREEVERYUSE
s #LOSECHOKE ).
s 4URNCLEANERCOVERKNOBCOUNTERCLOCKWISEBY
hand and remove air cleaner cover and air filter.
s "RUSHOFFDUSTLIGHTLYORWASHITINSUITABLE
cleanig fluid if necessary, or replace the air filter.
s $RYITCOMPLETELYBEFOREINSTALLATION
s 2EINSTALLAIRlLTERANDCOVER
CHECK FUEL SYSTEM
s #HECKBEFOREEVERYUSE
s !FTERREFUELINGMAKESUREFUELDOESNOTLEAK
from around fuel pipe, fuel grommet or fuel tank
cap.
s )NCASEOFFUELLEAKAGETHEREISADANGEROFlRE
Stop using the machine immediately and request
your dealer to inspect or replace.
SPARK PLUG
s #HECKPERIODICALLY
s 4HESTANDARDSPARKGAPISMM
(0.026 in.).
s #ORRECTTHESPARKGAPIFITISWIDERORNARROWER
than the standard gap.
s &ASTENINGTORQUE TO.·m
(130 to 145 in. lb.).
FUEL FILTER
s #HECKPERIODICALLY
s $ONOTALLOWDUSTTOENTERFUELTANK
s !CLOGGEDlLTERWILLCAUSEDIFlCULTYINSTARTING
engine or abnormalities in engine performance.
s 0ULLTHEFUELlLTEROUTTHROUGHFUELINLETPORTWITH
a piece of steel wire or the like.
s 7HENTHElLTERISDIRTYREPLACEIT
s 7HENTHEINSIDEOFTHEFUELTANKISDIRTYRINSING
the tank out with gasoline can clean it.
OIL FILTER
s #HECKPERIODICALLY
s $ONOTALLOWDUSTTOENTERINTOOILTANK
s !CLOGGEDOILlLTERWILLAFFECTTHENORMAL
lubricating system.
s 0ULLITOUTTHROUGHOILlLLINGHOLEWITHAPIECEOF
steel wire or the like.
s )FTHElLTERISDIRTYWASHITINGASOLINEORREPLACE
it.
s 7HENTHEINSIDEOFTHETANKGETSDIRTYRINSING
the tank out with gasoline can clean it.
Cylinder cover
Spark plug
