PB-500 H/T SPECIFICATIONS
X7505200007 31
© 02/2014 ECHO Inc.
SPECIFICATIONS
MODEL PB-500 H PB-500 T
Length (w/o pipes) 380 mm (15.0 in.) 328 mm (12.9 in.)
Width (w/o pipes) 545 mm (21.5 in.) 470 mm (18.5 in.)
Height (w/o pipes) 490 mm (19.3 in.)
Weight (dry) (w/o pipes) 9.4 kg (20.7 lb.) 9.2 kg (20.3 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 43.0 mm (1.69 in.)
Stroke 35.0 mm (1.38 in.)
Displacement 50.8 cc (3.10 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD,
two-stroke, air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10%
ethyl alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity 1.81 lit. (61.2 US fl. oz.)
Starter System Automatic Recoil Starter, centrifugal type
Idle Speed 2,650 RPM
Wide Open Throttle Speed (W.O.T.) 6,650 RPM
Average Air Speed w/pipes 72.87 m/sec (163 mph)
Maximum Air Speed w/pipes 87.17 m/sec (195 mph)
Air Volume 13.17 m
3
/min. (465 cu. ft./min.)
Sound Level at 50 ft. dB(A) scale per ANSI
B175.265 dB(A)
70 dB(A)

Echo PB-500 H Specifications

General

Engine Displacement	50.2 cc
Type	Backpack Blower
Power Source	Gasoline
Engine Type	2-stroke
Noise Level	70 dB(A)
