Echo PB-580 H User Manual

OPERATION PB-580 H/T
30 X7505200708
© 01/20 ECHO Incorporated
Starting Cold Engine
• Recoil starter: Use short pulls - only 1/2- 2/3 of rope length for starting.
Do not allow the rope to snap back in. Always hold the unit firmly.
• (PB-580H): Rotate spring loaded throttle arm downward to a comfortable
operating position.
1. Throttle Lever
Move throttle lever (A) to IDLE
position.
2. Choke
Move choke (B) UP to COLD
START ( ) position.
3. Purge Bulb
Pump purge bulb (C) until fuel is
visible. Pump bulb an additional
4 or 5 times.
4. Recoil Starter
Pull recoil starter handle (D) until
engine fires, or a maximum of 5 pulls
5. Choke
After engine fires (or 5 pulls),
move choke lever back to RUN
( ) position, then pull starter
handle/rope until engine starts
and runs. Allow unit to warm up
at idle for several minutes.
Note: If engine does not start
with choke in “RUN”
position after 5 pulls,
move choke to COLD
START ( ) position,
and repeat steps 3- 5.
6. Throttle Lever
Allow engine to warm up for several minutes before use.
7. Throttle Lever
After engine warm-up, move throttle lever gradually to increase engine
RPM to desired operating speed.
A
A
PB-580 H
PB-580 T
B
C
D

Echo PB-580 H Specifications

General

Engine Displacement	58.2 cc
Air Speed	215 MPH
Type	Backpack Blower
Engine Type	2-Stroke
Fuel Tank Capacity	1.1 L
