POWER EDGER
OPERATOR'S MANUAL
11
1. DEBRIS SHIELD/FLAP - Mounted over the cutting attachment. Helps protect operator by deflecting debris produced
during the edging operation.
2. BLADE - Rotates to provide cutting action.
3. WHEEL - Adjustable up/down, sets depth of blade.
4. GUARD DECAL (See page 4)
5. DRIVE SHAFT ASSEMBLY - Contains a specially designed liner and the flexible drive shaft.
6. SHAFT DECAL (SPANISH DECAL) (See page 4)
7. SHAFT DECAL (See page 4)
8. FRONT HANDLE - The front handle can be repositioned for comfortable operation by loosening the screws and moving
the handle.
9. STOP SWITCH -
PE-2000 - "Toggle Switch" mounted on the engine. Move switch UP to RUN, DOWN to STOP.
PE-2400/3100 - "Slide Switch" mounted on top of the throttle Trigger Housing. Move switch FORWARD to RUN, BACK
to STOP.
10. THROTTLE TRIGGER - Spring loaded to return to idle when released. When accelerating, press trigger gradually for
best operating technique.
11. GRIP - Rear (right hand) handle.
12. ARM REST - Provides arm rest during operation and protects arm from the hot engine.
13. CHOKE - The choke control is located on the top of the air filter case (PE-2400, 3100); side of the air filter case (PE-2000).
PE-2000 - Move lever to "COLD START" to close choke for cold starting. Move lever to "RUN" position to open choke.
PE-2400/3100 - Pull choke knob up to close choke for cold starting. Push knob down to "RUN" position to open choke.
14. SPARK PLUG - Provides spark to ignite fuel mixture.
15. MUFFLER/SPARK ARRESTOR -The spark arrestor muffler controls the exhaust noise and prevents hot, glowing
particles of carbon from leaving the muffler.
16. FUEL TANK - Contains fuel and fuel filter.
17. RECOIL STARTER HANDLE - Pull recoil handle slowly until starter engages, then quickly and firmly. DO NOT let
handle snap back or damage to unit will occur.
18. FUEL TANK CAP - Cover and seals fuel tank.
19. PRIMER BULB - Before starting and after filling the fuel tank, pump primer bulb 10 times or until a steady stream of fuel
without air is visible through the "clear" fuel return line.
20. AIR CLEANER - Contains replaceable felt element.
21. OPERATORS MANUAL - Read and understand this manual before operation. Keep manual in a safe location for future
reference, i.e., operation, maintenance, storage and specifications.
22. SAFETY MANUAL - Included in plastic bag (co-pack). Read before operation and keep in a safe place for future reference
to learn proper, safe operating techniques.
