14
FRONT HANDLE
Tools Required:Cross-Head Screwdriver
1. Assemble front handle and bracket loosely to drive shaft.
2. Position front handle in comfortable operating position and tighten
screws.
PE-2400
PE-3100
FRONT
HANDLE
NOTE
Steps 5, 6 & 7 required for PE-2400 and PE-3100 only.
5. Connect ignition leads (C).
6. (PE-2400) Secure ground lead under screw (D) on housing.
7. Install air filter and cover.
PE-2400
E
PE-3100
C
PE-2000
FRONT
HANDLE
To Next Page
