POWER EDGER
OPERATOR'S MANUAL
9
13
15
16
17
19
PE-2000
DESCRIPTION
EMISSION
CONTROL
The emission control system for this engine is EM (Engine
Modification).
An Emission Control Label is located on the engine. (This is an
EXAMPLE ONLY, information on label varies by engine
FAMILY).
IMPORTANT ENGINE INFORMATION
ENGINE FAMILY: TEH024UB24RC
DISPLACEMENT: 23.6 CC
THIS ENGINE MEETS U.S. EPA PH1 AND
1996 - 1998 CALIFORNIA EMISSION
REGULATIONS FOR ULGE ENGINES.
REFER TO OWNER'S MANUAL FOR
MAINTENANCE SPECIFICATIONS AND
ADJUSTMENTS.
KIORITZ CORP.
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions,
shield installation and positioning of the front handle are necessary.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
CONTENTS
__ 1, Edger Assembly
__ 1, Power Head
__ 1, Drive Shaft Assembly
__ 1, Plastic Bag (Co-Pack)
__ 1, Operators Manual
__ 1, Safety Manual
__ 1, Warranty Registration Card
__ 1, ECHO Emissions and Warranty Statement
__ 1, 50:1 1 Gal. ECHO Oil Mix
__ 1, Front Handle
__ 2, bolt 5x40 mm
__ 2, nut 5
__ 1, split pin
__ 1, Locking Tool
__ 1, 10 mm Spanner Wrench
__ Safety Glasses
1
14
18
20
21
22
2
3
4
5
6
7
10
11
12
8
9
__1, Scrench (Combination Spark Plug Socket/Screwdriver
