Echo PPT-266

Power Pruner
TM
oPeraTor's Manual
35
specIfIcatIons
MODEL ---------------------------------------------------- PPT-266/H/S
Length (Standard) (PPT-266/H) ------------------------- 2.72 m (8 ft. 11 in.)
Length (Standard) (PPT-266S) --------------------------- 1.96 m (6 ft. 5 in.)
Length (Extended) (PPT-266/H) ------------------------- 3.71 m (12 ft. 2 in.)
Length (Extended) (PPT-266S) -------------------------- 2.41 m (7 ft. 11 in.)
Length w/extension (PPT-266/H) ------------------------ 4.93 m (16 ft. 2 in.)
Length w/extension (PPT-266S) ------------------------- 3.94 m (12 ft. 11 in.)
Width (PPT-266/H) ---------------------------------------- .25 m (9.8 in.)
Width (PPT-266S) ----------------------------------------- .25 m (9.8 in.)
Height (PPT-266/H) --------------------------------------- .25 m (9.7 in.)
Height (PPT-266S/H)-------------------------------------- .25 m (9.7 in.)
Weight (dry) (PPT-266) ----------------------------------- 8.4 kg (18.5 lb.)
Weight (dry) (PPT-266H) --------------------------------- 8.2 kg (18.0 lb.)
Weight (dry) (PPT-266S) --------------------------------- 7.5 kg (16.5 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 34.0 mm (1.34 in.)
Stroke -------------------------------------------------------- 28.0 mm (1.10 in.)
Displacement ----------------------------------------------- 25.4 cc (1.55 cu. in.)
Exhaust System -------------------------------------------- Spark arrestor - catalytic mufer / mufer
Carburetor--------------------------------------------------- Diaphragm model w/purge pump
Ignition System -------------------------------------------- CDI (capacitor discharge ignition)
Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ---------------------------------------------- 50 : 1 Power Blend X™ ISO-L-EGD (ISO/CD 13738) and
J.A.S.O. M345- FD, two-stroke, air-cooled engine oil.
Gasoline ----------------------------------------------------- Use 89 Octane unleaded. Do not use fuel containing methyl
alcohol, more than 10% ethyl alcohol or 15% MTBE. Do not use
alternative fuels such as E-15 or E-85.
Oil ------------------------------------------------------------ Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.50 lit. (16.9 US . oz.)
Starter System ---------------------------------------------- Automatic Recoil Starter
Clutch-------------------------------------------------------- Centrifugal Type
Sprocket Type ---------------------------------------------- 6 tooth spur, 9.53 mm (3/8 in.) pitch
Power Transmission Shaft Assembly ------------------- Aluminum Extrusion
Gear Case Ratio -------------------------------------------- 1.5:1
Oiling System ---------------------------------------------- Automatic
Saw Chain Oil Capacity ---------------------------------- 225 ml (7.6 oz.)
Handle ------------------------------------------------------- Right hand grip w/throttle trigger and lockout
Shoulder Harness ------------------------------------------ Standard
Idle Speed (RPM) ------------------------------------------ 2,850
Clutch Engagement Speed (RPM) ----------------------- 3,900
Wide Open Throttle Speed (RPM) ---------------------- 10,750
Guide Bar and Saw Chain (90) -------------------------- 305 mm (12 in.); 9.53 mm (3/8 in.) pitch, 0.043 gauge
