X7502257007 19
© 4/2016 ECHO Inc.
SHC-225/S OPERATION
Stored two-stroke fuel may separate. ALWAYS shake fuel container
thoroughly before each use.
Starting Cold Engine
Hedge Trimmer blades are very sharp. Touching them may lead to
severe personal injury. Avoid touching blades whenever possible,
and always wear gloves to protect hands.
Note: The blade cover is used for transportation and storage. Remove
blade cover before using the unit.
The attachment will operate immediately when the engine starts,
and could result in possible serious injury. Keep movable parts of
the attachment away from objects that could become entangled or
thrown, and surfaces that could cause loss of control.
1. Stop Switch
Move stop switch (A) away from
the STOP position.
2. Choke
Move choke (B) to Cold Start
( ) (closed) position.
3. Purge Bulb
Pump purge bulb (C) until fuel is
visible and flows freely in the
clear fuel tank return line. Pump
bulb an additional 4 or 5 times.
To Next Page
