X7502257007 21
© 4/2016 ECHO Inc.
SHC-225/S OPERATION
1. Stop Switch
Move stop switch (A) away from the
STOP position.
2. Purge Bulb
Pump purge bulb (C) until fuel is
visible and flows freely in the clear fuel
tank return line. Pump bulb an
additional 4 or 5 times.
3. Recoil Starter
Lay the unit on a flat area and keep
movable attachment parts clear of all
obstacles. Firmly grip throttle handle
and throttle trigger lockout with left
hand. Rapidly pull recoil starter
handle/rope (D) until engine fires.
Note: If engine does not start after 5
pulls, use Cold Start
Procedure.
Stopping Engine
1. Throttle
Release throttle and allow engine to
return to idle before shutting off
engine.
2. Stop Switch
Move stop switch (A) to STOP
position.
To Next Page
