Echo SHC-225S User Manual

X7502257007 27
© 4/2016 ECHO Inc.
SHC-225/S MAINTENANCE
1. Remove spark plug lead.
2. Remove air cleaner cover (A).
3. Remove engine cover (B).
DO NOT use a metal scraper to remove dirt from the cylinder fins.
4. Use brush to remove dirt from the
cylinder fins.
5. Remove ignition wires from clip for
cleaning.
6. Remove grass and leaves from the
grid between the recoil starter and
fuel tank.
7. Assemble components in reverse
order.
Exhaust System
Spark Arrestor Screen
Level 2.
Parts Required: Spark Arrestor Screen, Gasket
A
B
