SHC-225/S MAINTENANCE
Gear Case
Level 1.
1. Clean dirt from the grease fitting
(A).
2. Carefully pump grease into fitting
(A). DO NOT force grease. Too
much pressure will force grease
past seals and cause damage.
Apply 1 - 2 pumps of grease every
15 - 25 hours of operation.
3. Wipe excess grease from around
grease fitting.
Drive Shaft Assembly
Level 1.
Hedge Trimmer blades are very sharp. Touching them may lead to
severe personal injury. Avoid touching blades whenever possible,
and always wear gloves to protect hands.
1. Remove gear housing locating
screw (A) and loosen clamping
screw (B). Remove the gear
housing assembly from the drive
shaft housing.
Parts Required: Lithium Based Grease.
Parts Required: Lithium Based Grease.
To Next Page
