X7502257007 33
© 4/2016 ECHO Inc.
SHC-225/S MAINTENANCE
1. Move stop switch to STOP
position.
2. Disconnect spark plug wire.
3. Remove blade guard, if installed
(see “Blade Guard Remove/
Install instructions”).
4. Slide blades to allow file
clearance using slots (A) on
bottom of blade. Do not pry
against cutting edges.
5. File each edge carefully. Follow
the original shape of the blade.
If a power grinder is used DO NOT allow blade to over heat.
6. Install blade guard, if necessary (see “Blade Guard Remove/Install
instructions”).
7. Lubricate blades (see “Lubrication”).
8. Connect spark plug wire.
Adjustment
Level 2.
Hedge Trimmer blades are very sharp. Touching them may lead to
severe personal injury. Use long hex wrenches and sockets with
extensions when tightening blade screws and blade lock nuts to
keep hands at a safe distance from sharp blades.
Parts Required: none
