Page #10 background image
TORNILLO - 5X20SCREW - 5X202V8050001601
SOPORTE,TUBO PRINCIPAL - SUPERIORHOLDER, MAIN PIPE - UPPER1610922274322
SOPORTE,TUBO PRINCIPAL - INFERIORHOLDER, MAIN PIPE - LOWER1610923552303
COJÍNCUSHION1610910552304
TORNILLO - 4X16 -- TORXSCREW - 4X164V8040000605
CONJUNTO DE CARCASA DEL VENTILADORFAN CASE ASY1P0210155606
PASADOR DE POSICIONAMIENTOPIN, LOCATING2+ V6220000207
ANILLO, RETÉN - 12RING, RETAINING - 121+ 900701000128
COJINETE DE BOLAS - 6001BEARING, BALL - 60012+ 900807960019
ANILLO, RETÉN - 28RING, RETAINING - 281+ 9007020002810
TAMBOR, EMBRAGUEDRUM, CLUTCH1+ 1750054893111
CONJUNTO DE EMBRAGUECLUTCH ASY1A05600023012
- 9 -
SRM-225 TRIMMER
Recortadora Fan Case, Clutch
Carcasa del Ventilador, Embrague
