TORNILLO - 4X8 -- TORXSCREW - 4X8 -- TORX3V8040000801
GUÍA, ESCAPEGUIDE, EXHAUST1A3130005802
JUNTA, ESCAPE
(1)
GASKET, EXHAUST
(1)
1145866420313
PANTALLA, SUPRESOR DE CHISPASSCREEN, SPARK ARRESTER1145862406304
TORNILLO - 5X55SCREW - 5X552V8050001905
ARANDELA - 5WASHER2900600000056
CONJUNTO DE SILENCIADORMUFFLER1145806420307
PROTECTOR, ESCAPE
(1)
SHIELD, EXHAUST
(1)
1V1040008508
TORNILLO - 5X16SCREW - 5X161V8050001509
TORNILLO - 5X16SCREW - 5X161V80500000010
DUCTO, AIREDUCT, AIR1A32000048011
1 - Incluido en KIT de la JUNTA(NOTA DEL PIE)1 - Included In GASKET KIT(FOOTNOTE)
- 8 -
SRM-225 TRIMMER
Recortadora Exhaust
Escape
