DRIVESHAFT - FLEXIBLEDRIVESHAFT - FLEXIBLE1C5060003901
CONJUNTO DE TUBO PRINCIPALMAIN PIPE ASY1C0500010902
DETENEDORSTOPPER2+ 610246447303
FORRO - FLEXIBLELINER - FLEXIBLE1+ C5070002604
ETIQUETA - PRECAUCIÓNLABEL - CAUTION1+ X5050025005
ETIQUETA - UBICACIÓN DEL MANGOLABEL - HANDLE LOCATION1+ X5050019306
ETIQUETA - ALINEACIÓNLABEL - ALIGNMENT1+ 890152049307
- 18 -
SRM-225 TRIMMER
Recortadora Main Pipe Assembly, Driveshaft
Conjunto del Tubo Principal, Eje de Mando
