CABEZAL DE RECORTADORA SPEED-FEED 400SPEED-FEED 400 TRIMMER HEAD199944200907B1
TAPALID1+ E4150001802
CONJUNTO DE CARRETESPOOL HOUSING ASY1+ X4700003303
OJALEYELET2+ X4750001104
CUBO - NEGRO -- ROSCA IZQUIERDAHUB - BLACK -- LEFT HAND1+ X4760000405
ARBOR - ORO -- ROSCA IZQUIERDAARBOR - GOLD -- LEFT HAND1+ V1600001506
CARRETESPOOL1+ X4730001307
RETENEDOR, RESORTERETAINER, SPRING1+ V4940008408
RESORTESPRING1+ V4500018809
ESTUCHECASE1+ X47200007010
- 13 -
SRM-225 TRIMMER
Recortadora SPEED-FEED 400 Trimmer Head
Cabeza SPEED-FEED 400 de Recortadora
