Echo SRM-225 User Manual

X7722279402 27
© 2/2016 ECHO Inc.
SRM-225 OPERATION
Note: If attachment moves, readjust carburetor according to
“Carburetor Adjustment” instructions in this manual or see your
ECHO Dealer.
1. Stop Switch
Move stop switch button (A)
forward away from the STOP
position.
2. Purge Bulb
Pump purge bulb (C) until fuel
is visible in the “Clear” fuel
return line. Pump bulb an
additional 4 or 5 times.
3. Recoil Starter
Lay the unit on a flat area and
keep movable attachment
parts clear of all obstacles.
Firmly grip throttle handle and
throttle trigger lockout with left
hand. Rapidly pull recoil
starter handle/rope (D) until
engine fires.
Note: If engine does not start
after 5 pulls, use Cold
Start Procedure.
A
C
D

Echo SRM-225 Specifications

General

Engine Displacement	21.2 cc
Cutting Swath	17 inches
Engine Type	2-stroke
Carburetor	Diaphragm
Shaft Type	Straight
Fuel Capacity	14.9 fl. oz
Fuel Tank Capacity	14.9 fl. oz
Warranty	5 year consumer / 2 year commercial
