Echo SRM-225 User Manual

X7722279402 37
© 2/2016 ECHO Inc.
SRM-225 MAINTENANCE
1. Press top of locking tabs (A) on
both sides of Speed Feed®
head to release cover (B) from
eyelet carrier (C).
2. Remove cover from eyelet
carrier.
Nylon Line Replacement
For more information scan the QR code.
Wear Gloves or personal injury may result:
◆ Cutoff knife is sharp.
◆ Gearcase and surrounding area may be hot.
1. Cut one piece of line to
recommended length.
2.0 mm (.080) diam. – 6 m
(20 ft.)
2.4 mm (.095) diam. – 6 m
(20 ft.)
2. Align arrows on top of knob
with openings in eyelets.
3. Insert one end of trimmer line
into an eyelet, and push line
equal distance through
trimmer head.
A
B
C

Echo SRM-225 Specifications

General

Engine Displacement	21.2 cc
Cutting Swath	17 inches
Engine Type	2-stroke
Carburetor	Diaphragm
Shaft Type	Straight
Fuel Capacity	14.9 fl. oz
Fuel Tank Capacity	14.9 fl. oz
Warranty	5 year consumer / 2 year commercial
