MAINTENANCE SRM-225
30 X7722279402
© 2/2016 ECHO Inc.
Air Filter
Level 1.
1. Close choke (COLD START [ ] position). This prevents dirt from
entering the carburetor throat when the air filter is removed. Brush
accumulated dirt from air cleaner area.
2. Remove air filter cover. Brush dirt from
inside cover.
3. Replace filter if it is damaged, fuel soaked,
very dirty, or the rubber sealing edges are
deformed.
• Lightly brush debris from filter.
• Soak heavily soiled filters in water/
detergent solution to loosen dirt, then
brush lightly.
• Rinse with clean water and allow to dry
completely before reuse.
4. Install air filter in air filter case.
5. Install air filter cover.
Fuel Filter
Level 1.
Fuel is VERY flammable. Use extreme care when mixing, storing or
handling, or serious personal injury may result.
1. Use a clean rag to remove
loose dirt from around fuel cap
and empty fuel tank.
2. Pull the fuel filter from the fuel
tank.
3. Remove the filter from the line
and install the new filter.
Parts Required:
REPOWER
TM
AIR & FUEL FILTER KIT.
Parts Required:
REPOWER
TM
AIR & FUEL FILTER KIT.

Echo SRM-225 Specifications

General

Engine Displacement	21.2 cc
Cutting Swath	17 inches
Engine Type	2-stroke
Carburetor	Diaphragm
Shaft Type	Straight
Fuel Capacity	14.9 fl. oz
Fuel Tank Capacity	14.9 fl. oz
Warranty	5 year consumer / 2 year commercial
