Echo WT160S Parts Manual

WHEELED TRIMMER
9
7/10
Self-Propelled
WT160S & WT190S
DRIVE ASSEMBLY
ASSEMBLY, WHEELED TRIMMER DRIVE
ITEM PART NUMBER DESCRIPTION
WT160S
QTY
WT190S
QTY
1 12319 PULLEY, 5.0 X 7/8 AB 1 1
2
12512 ENGINE, 5.5 HP HONDA GCV 1
18945-00 ENGINE, 6.5 HP QUANTUM HD 49 STATE 1
3 12568 PULLEY, 7-1/2 X 12MM A GROOVE 1 1
4 12571 SPROCKET, 35A60 W/HOLES 2 2
5 12572 CHAIN, EZ TRIMMOWER 2 2
6 12574 BEARING, 1/2 FLANGE 2 2
7
12755 DECAL, 5.5 HP INFORMATION 1
14564-00 DECAL, 6.5 HP SP INFORMATION 1
8 12834 TRANSMISSION, 3 SPEED 1 1
9 15131 SCREW, 5/16-18 X 5/8 SQ HD SET 2 2
10 15154 BOLT, 5/16 X 2-1/2 HEX HD GR5 ZP 1
11 15180 SET SCREW, 1/4 X 5/8 SQ HD 2 2
12 15238 BOLT, 1/4 X 3/4 CRG GR5 ZP 4 4
13 15250 WASHER, 5/16 FLAT ZP 8 8
14 15282 BOLT, 5/16 X 1-1/2 HEX HD GR5 ZP 3 2
15 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP 10 10
16 15355 NUT, 1/4 NE NYLOCK ZP 4 4
17 15356 NUT, 5/16 NE NYLOCK ZP 19 19
18 15372 KEY, 3/16 SQUARE X 1.00 LONG 1 1
19 15397 NUT, 10/24 NYLOCK TYPE NM, ZP 2 2
20 15406 PUSHNUT, 5/8 ZP 2 2
21 15416 WASHER, 5/16 SAE FLAT ZP 5 3
22 15560 BOLT, 5/16 X 2-3/4 HCPS GR5 6 6
23 15594 SCREW, #10X24 X 1-1/2 PAN PHP ZP 2 2
24 15598 KEY, 4MM SQUARE X 20 MM 1 1
25 15680-00 SCREW, #8-32 X 3/16 KNR CUP PT 1 1
26 15683-00 CLIP, 1/2" E 2 2
27 16155 DECAL, SERIAL NUMBER 1 1
28 16900 STRAP, 4 IN. BLACK 1 1
29 18950-00 RIVET, PLASTIC 1/4 X 7/8 4 4
30 31310-00 MUFFLER DEFLECTOR, HONDA 5.5 HP GCV 1
31 31311-00 SCREW, MUFFLER DEFLECTOR 2
32 72723 FLAP, TRIMMER 1 1
33 72989 WELDMENT, LH WHEEL CLUTCH 1 1
34 72990 WELDMENT, RH WHEEL CLUTCH 1 1
35 73266-12 PAN, TRIMMER BOTTOM 1 1
36 73630-35 BODY, TRIMMER 1 1
37 74836-00 TUBE, 1.5" X 2.125" HEAT SHRINK 2 2
38 75512-12 SHEET, CAP WHEEL 2 2
39 75534-00 ASSEMBLY, TRIMMER WHEEL 2 2
40 76733-12 BOTTOM, TRIMMER FRAME 1 1
41 76734-12 PLATE, TRANSMISSION 1 1
42 76736-12 WELDMENT, TRIMMER AXLE 1 1
