WHEELED TRIMMER

7/10

Push w/Tilt

WT160T & WT190T

HANDLEBAR ASSEMBLY

ASSEMBLY, WT160T & WT190T HANDLEBAR

ITEM PART NUMBER DESCRIPTION

1 12324 CABLE, BRAKE CONTROL

2 12326 PAD, FOAM HANDLEBAR

3 15030 WASHER, 1/4 FLAT ZP

4 15176 SCREW,11/32 X 7/8 HWH AB THREAD ZP

5 15197 BOLT, 1/4 X 2-1/4 HCS GR5 ZP (WT160T MODELS)

15342 BOLT, 1/4 X 1-1/2 HCS GR5 ZP (WT190T MODELS)

6 15219 BOLT, 5/16 X 1 HHCS GR5 NC ZP

7 15250 WASHER, 5/16 FLAT ZP

8 15355 NUT, 1/4 NE NYLOCK ZP

9 15356 NUT, 5/16 NE NYLOCK ZP

10 15403 BOLT, 5/16-18 X 1-3/4 HCS GR5 ZP

11 15754-00 BOLT, 5/16 X 2-1/4 HCPS GR5

12 16239 THROTTLE CONTROL (WT160T MODELS)

13 16740 DECAL, THROTTLE (WT160T MODELS)

14 17320 STRAP, 11 IN. BLACK TIE

15 18008-00 CONTAINER, MANUAL

16 18955-00 CAP, PLASTIC 3/4 X 1-1/2 TUBE

17 72732-12 BAIL, TRIMMER

18 72760 HANDLEBAR, TRIMMER

19 74964-12 TUBE, CONTAINER MANUAL

20 75518-12 CHANNEL, HANDLE SUPPORT
