WHEELED TRIMMER
11
7/10
Self-Propelled
WT160S & WT190S
HANDLEBAR ASSEMBLY
ASSEMBLY, WT160S & WT190S HANDLEBAR
ITEM PART NUMBER DESCRIPTION
1 12324 CABLE, BRAKE CONTROL
2 12326 PAD, FOAM HANDLEBAR
3 12842 CABLE, TRANSMISSION CONTROL
4 12849 DECAL, 3 SPEED
5 12856 CABLE, SP CONTROL
6 15030 WASHER, 1/4 FLAT ZP
7
15093 BOLT, 1/4 X 2 HEX HD GR5 ZP (WT160S ONLY)
15094 BOLT, 1/4 X 1-3/4 HHCS GR5 ZP (WT190S ONLY)
8 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
9
15197 BOLT, 1/4 X 2-1/4 HCS GR5 ZP (WT160S ONLY)
15342 BOLT, 1/4 X 1-1/2 HHCS GR5 ZP (WT190S ONLY)
10 15219 BOLT 5/16 * 1" GR5 HHCS NC ZP
11 15250 WASHER, 5/16 FLAT ZP
12 15355 NUT, 1/4 NE NYLOCK ZP
13 15356 NUT, 5/16 NE NYLOCK ZP
14 15403 BOLT 5/16-18 X 1-3/4 HCS GR5 ZP
15 15754-00 BOLT, 5/16 X 2-1/4 HCPS GR5
16 16239 THROTTLE CONTROL (WT160S ONLY)
17 17320 STRAP, 11 IN. BLACK TIE
18 18008-00 CONTAINER, MANUAL
19 18955-00 CAP, PLASTIC 3/4 X 1-1/2 TUBE
20 72732-12 BAIL, TRIMMER
21 72760 HANDLEBAR, TRIMMER
22 72995-12 WELDMENT, SP BAIL
23 72999-12 ANCHOR, SP CABLE
24 73630-35 BODY, TRIMMER
25 74964-12 TUBE, CONTAINER MANUAL
26 75518-12 CHANNEL, HANDLE SUPPORT
27 76733-12 BOTTOM, TRIMMER FRAME
