WHEELED TRIMMER
13
7/10
Self-Propelled
WT160S & WT190S
HEAD ASSEMBLY
ASSEMBLY, WT160S & WT190S HEAD
ITEM PART NUMBER DESCRIPTION
1 12252 DECAL, VAC DEBRIS
2 12254 DECAL, GRINDER DANGER
3 12314 BEARING, 3/4 BALL
4 12348 STRING, .155 X 20-1/2
5 12573 BELT, 3L X 52
6
14182-00 DECAL, 98 DB
14184-00 DECAL, 101 DB
7 14942-00 DECAL, MULTILINGUAL MANUAL
8 14984-00 DECAL, PROTECTION
9 15003 BOLT, 5/16 3/4 HEX HD GR5 ZP
10 15098 WASHER, 3/4 SAE FLAT ZP
11 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
12 15250 WASHER, 5/16 FLAT ZP
13 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP
14 15356 NUT, 5/16 NE NYLOCK ZP
15 15402 NUT 5/16-18 TINNERMAN U-TYPE
16 72705-12 DISK, TRIMMER HEAD
17 72754 WELDMENT, TRIMMER PULLEY
18 72755-12 WELDMENT, SPINDLE HUB
19 72759 SPACER, TRIMMER SPINDLE
20 72781-00 SPACER, TRIMMER HEAD
21 73116-12 WELDMENT, TRIMMER HEAD USE 72704-12
22 73630-35 BODY, TRIMMER
23 75519-35 COVER, FRONT TRIMMER
24 76733-12 BOTTOM, TRIMMER FRAME
