Echo WT160S Parts Manual

WHEELED TRIMMER
15
7/10
Push w/Tilt
WT160T & WT190T
DRIVE ASSEMBLY
ASSEMBLY, WT160T & WT190T DRIVE
ITEM PART NUMBER DESCRIPTION
WT160T
QTY
WT190T
QTY
1 12177 SPRING, HEAVY DUTY COMPRESSION 1 1
2 12275 FITTING, 1/4 SELF-TAP GREASE 1 1
3 12319 PULLEY, 5.0 X 7/8 AB 1 1
4 12325 GRIP, TILT CONTROL 1 1
5 12512 ENGINE, 5.5 HP HONDA GCV 1
18945-00 ENGINE, 6.5 HP QUANTUM HD 49 STATE 1
6 12520 DEFLECTOR, EXHAUST (WT160T ONLY) 1
7 12755 DECAL, 5.5 HP INFORMATION 1 1
8 15003 BOLT, 5/16 X 3/4 HEX HD GR5 ZP 4 4
9 15129 WASHER, 5/8 SAE FLAT ZP 4 4
10 15131 SCREW, 5/16-18 X 5/8 SQ HD SET 2 2
11 15154 BOLT, 5/16 X 2-1/2 HEX HD GR5 ZP 1 2
12 15250 WASHER, 5/16 FLAT ZP 7 7
13 15282 BOLT, 5/16 X 1-1/2 HEX HD GR5 ZP 3 2
14 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP 3 3
15 15356 NUT, 5/16 NE NYLOCK ZP 12 12
16 15375 PIN, 1/8 X 1.00 COTTER ZP 2 2
17 15406 PUSHNUT, 5/8 ZP 2 2
18 15416 WASHER, 5/16 SAE FLT ZP 3 3
19 15434 KEY, 3/16 SQUARE X 1-1/2 LONG PLAIN 1 1
20 16155 DECAL, SERIAL NUMBER 1 1
21 17897 BEARING, SIDE FLANGE MOUNT, 5/8 2 2
22 18957-00 WHEEL, 15 INCH TRIMMER (BLACK) 2 2
23 72710-12 WELDMENT, AXLE PIVOT 1 1
24 72724 HANDLE, TRIMMER HEIGHT ADJUST 1 1
25 72736-12 PLATE, HANDLE LOCK 1 1
26 72762-12 SPACER, 7/8 X .281 3 3
27 73298-35 WELDMENT, TRIMMER BODY 1 1
28 75505-12 WELDMENT, TRIMMER AXLE 1 1
