WHEELED TRIMMER
3
7/10
Push
WT190 DRIVE ASSEMBLY
ASSEMBLY, WT190 DRIVE
ITEM PART NUMBER DESCRIPTION
1 12319 PULLEY, 5.0 X 7/8 AB
2 14560-00 DECAL, 6.5 HP INFORMATION
3 15131 SCREW, 5/16-18 X 5/8 SQ HD SET
4 15154 BOLT, 5/16 X 2-1/2 HEX HD GR5 ZP
5 15219 BOLT, 5/16 X 1 HHCS GR5 NC ZP
6 15250 WASHER, 5/16 FLAT ZP
7 15282 BOLT, 5/16 X 1-1/2 HEX HD GR5 ZP
8 15301 BOLT, 5/16 X 1 CRG GR5 ZP
9 15356 NUT, 5/16 NE NYLOCK ZP
10 15406 PUSHNUT, 5/8 ZP
11 15416 WASHER, 5/16 SAE FLAT ZP
12 15434 KEY, 3/16 SQUARE X 1-1/2 LONG PLAIN
13 16155 DECAL, SERIAL NUMBER
14 18945-00 ENGINE, 6.5 HP QUANTUM HD 49 STATE
15 18957-00 WHEEL, 15 INCH TRIMMER (BLACK)
16 69126 SPACER, IDLER PIVOT
17 73630-35 BODY, TRIMMER
18 75503-12 WELDMENT, TRIMMER AXLE
19 75504-12 BOTTOM, TRIMMER FRAME
To Next Page
