WHEELED TRIMMER
7
7/10
Push
WT190 HEAD ASSEMBLY
ASSEMLBY, WT190 HEAD
ITEM PART NUMBER DESCRIPTION
1 12254 DECAL, GRINDER DANGER
2 12314 BEARING, 3/4 BALL
3 12317 BELT, 4L 53 ARAMID
4 12348 STRING, .155 X 20-1/2
5 14184-00 DECAL, 101 DB
6 15003 BOLT, 5/16 X 3/4 HEX HD GR5 ZP
7 15098 WASHER, 3/4 SAE FLAT ZP
8 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
9 15250 WASHER, 5/16 FLAT ZP
10 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP
11 15356 NUT, 5/16 NE NYLOCK ZP
12 15402 NUT, 5/16-18 TINNERMAN U-TYPE
13 18949-00 DECAL, MANUAL/SAFETY INFO
14 18950-00 RIVET, PLASTIC 1/4 X 7/8
15 72705-12 DISK, TRIMMER HEAD
16 72723 FLAP, TRIMMER
17 72754 WELDMENT, TRIMMER PULLEY
18 72755-12 WELDMENT, SPINDLE HUB
19 72759 SPACER, TRIMMER SPINDLE
20 72781-12 SPACER, TRIMMER HEAD
21 73116-12 WELDMENT, TRIMMER HEAD USE 72704-12
22 73630-35 BODY, TRIMMER
23 75504-12 BOTTOM, TRIMMER FRAME
24 75519-35 COVER, FRONT TRIMMER
