Eclipse ThermAir T/A Series v1.10, Installation Guide No. 114, 4/7/06
17
Adjustment, Start &
Stop
4
In this chapter you will find instructions on how to start and
stop a burner. The chapter begins with general instructions
that are useful for adjustment.
Adjustment
There are two separate system adjustment procedures:
• System 1
Adjust a ThermAir burner with a ratio-regulator
iNtroDuCtioN
Danger:
The ThermAir burners, described herein, are
designed to mix fuel with air and burn the
resulting mixture. All fuel burning devices are
capable of producing fires and explosions if
improperly applied, installed, adjusted, controlled,
or maintained.
Do not bypass any safety feature; fire or explosion
could result.
Never try to light a burner if it shows signs of
damage or malfunction.
• System 2
Adjust a ThermAir burner without a ratio-regulator
system 1
burNer aDjustmeNt
With a Ratio-Regulator
If you are adjusting a ThermAir burner equipped with a ratio-
regulator for the first time, you must follow these steps:
1. Reset the system
2. Verify air flow
3. Ignite the burner
4. Set high fire gas
5. Set low fire gas
6. Verify gas settings
7. Stop Procedure
1. Close these valves
- the automatic gas valves
- the manual gas cocks
2. Start the combustion air blower
Step 1: Reset the system
