18
JET, COMPONENT AND EQUIPMENT OPERATING INSTRUCTIONS
See Pages 23 - 26 for Model E1-E2-E3-E4
Locations of Jets, Components & Equipment
JET OPERATION
Your ECO SPA is designed with a versatile jet system to allow you to select a wide variety of
massage patterns and tailor your ECO SPA to your specific massage and hydrotherapy
needs.
MASSAGE JETS
AIR CONTROLS
DIRECTIONAL JETS (2” or 3”) produce a tight massage stream
with that of 2” jets slightly more vigorous than that of larger 3”
jets.
To adjust the flow of Directional Jets toward a particular part of
your body, rotate the nozzle ("eyeball") of the jet to aim it in the
desired direction.
ROTO (Rotational) JETS (3” or 4-3/8”) provide a loose, swirling
massage stream with 4-3’8” jets slightly ‘softer’ than that of
smaller 3” jets.
To adjust the flow pressure of either a Directional or Roto Jet,
turn the OUTER RING counter-clockwise to increase flow to a
maximum and clockwise to decrease flow to a minimum or Off.
DO NOT FULLY DECREASE (CUT OFF) FLOW OF ALL OF THE JETS AT THE SAME TIME as this
may cause your pump to malfunction and could cause your ECO SPA to leak.
The two AIR CONTROLS are used to introduce air into the water
flow of the Massage Jets for more robust, vigorous massage.
Turn the Air Control knob counter-clockwise to the Open position to
increase jet pressure, and clockwise to the Closed position to
decrease jet pressure.
Note: When you are not using your ECO SPA and the covers are closed, ensure that the Air
Control knobs are in the CLOSED position.
This will prevent air from entering the water stream to help to maintain your water
temperature more efficiently when your ECO SPA is heating or in Filter Mode.
