Ecoer EAHAEC-60 - 3.9 Electrical Wiring Diagrams

18/157
SDi Decades Extreme Service Manual www.ecoer.com
May. 2023Manufacturer reserves the right to change specifications or designs without notice.
IDU Capacity (Btu/h)
IDU Wiring Diagram
36k/60k
16023000011626
Abbreviation
Paraphrase
Y/G
Yellow-Green Conductor
CAP
Indoor Fan Capacitor
FAN
Indoor Fan Motor
ECM
Indoor ECM Motor
TO CCM Comm.Bus
Central Controller
T1
Indoor Room Temperature Sensor
T2A
Indoor Coil Inlet Temperature Sensor
T2B
Indoor Coil Outlet Temperature Sensor
T2
Indoor Coil Temperature Sensor
3.9 Electrical Wiring Diagrams
