EcoFlow PowerOcean Plus - Page 11

|9
Efciency
Max. Efciency 98.0%
European Efciency 97.0%
Max. MPPT Efciency 99.9%
Compliance
Certicates CE mark
Safety Standards IEC/EN 62109-1, IEC/EN 62109-2
Grid-tied Standards
VDE-AR-N-4105, TOR Erzeuger Typ A, EN 50549, PTPiREE, G99,
TF 3.3.1 (B1.2 for type A), CEI 0-21, C10/11, UNE, NTS
EMC&RF
EN 301 489-1
EN 301 489-3
EN 301 489-17
EN 300 328
EN 301 893
EN 300 440
EN IEC 61000-6-1
EN IEC 61000-6-2
EN IEC 61000-6-3
EN IEC 61000-6-4
EN 61000-3-11
EN 61000-3-12
EN IEC 62311
EN 62311
EN 50665
Protection
PV Insulation Resistance Detection Yes
Residual Current Monitoring Yes
PV Reverse Polarity Protection Yes
Anti-islanding Protection Yes
AC Overcurrent Protection Yes
Backup Load Short Circuit Protection Yes
AC Overvoltage Protection Yes
DC Switch Yes
Remote Shutdown Yes
Protective Class I
DC Surge Protection Type II
AC Surge Protection Type II
General
Operating Temperature Range (°C) –20 to 50
Relative Humidity 0-100%
Max. Operating Altitude (m) 3000
Cooling Method Intelligent air cooling
User Interface LED indicator, EcoFlow app
Communication Method
RS485 (for meter) & CAN (for BMS) & Wi-Fi & Bluetooth & WAN &
4G
Wi-Fi Frequency Range (MHz)
Maximum Output Power (dBm)
2.4GHz: 2412-2472, 5GHz: 5180-5700, 5745-5825
<20
Bluetooth Frequency Range (MHz)
Maximum Output Power (dBm)
2402-2480,
<8
Weight (kg) Approx. 41
Dimension (W×D×H mm)
636×235×498 (±1) (with trim cover)
636×235×419 (±1) (without trim cover)
Noise Emission (dB) <45
Topology Non-isolated
Self-consumption at Night (W) <20.5
Ingress Protection Rating IP65
Environmental Category Outdoor/Indoor
Pollution Degree PD3
Storage Temperature (°C) –30 to 60
Mounting Method Wall Mounted
