ASSEMBLY INSTRUCTIONS
For Folding Fatbike
Guide for folding:
Battery Operation For Folding Fatbike
 To remove or insert the battery
The battery is fully inserted in the battery holder, to remove the battery, turn the key
to the "Off" position and press the key to "UNLOCK" position, lift the battery vertical
from top side of the battery, and remove or insert the battery. The key switch must be
in the unlock position to slide the battery in and out.
 Power on/off switch ( See Figure 1 )to turn on/off the power. Switch to "on"
position.
 Charging of battery
To charge the battery, plug the charger into an AC outlet. Then plug the charger plug
into the charging port on the bike(see Figure 2).
Figure 1 Figure 2
How to fold head stem vertically.
How to fold frame.
