ECOVACS DD4G - 2. Package Contents and Technical Specifications; 2.1 Package Contents; 2.2 Specifications

EN
6
2. Package Contents and Technical Specifications
2.1 Package Contents
Robot
(4) Side Brushes
(2) Washable/Reusable
Main Brush Option
(Pre-installed)
Cleaning Cloth Plate
Docking Station Remote Control with Batteries Instruction Manual
Model DD4G, DD4G.**(*=0-9)
Working Voltage 12V DC Rated Power 40W
Docking Station Model CH1630A
Rated Input Voltage 100-240V AC Rated output voltage 20V DC
Rated Output Current 0.8A Rated power
25W
Remote Control Model RC1633
Input Voltage 3V DC
Remote Control Battery Type AAA
Nominal Voltage 1.5V DC
Battery
DM88-BYD 3000mAh
Frequency bands 2412-2472MHz
Maximum RF power transmitted
in the frequency band
Max PA output power at 72.2 Mbps: 17.5 dBm
Max PA output power in 11b mode: 21.5 dBm
2.2 Specifications
*
Output power of the WIFI module is less than 100mW.
Direct Suction Option
Sponge Filter and
Reservoir
