EcoWater ESM9CE+ - Dimensions

”
IN -- OUT
14”
14”
F
E
16”
16”
36--9/16
32”
IN
OUT
3--3/8”
32--1/2”
45--1/8”
D
IN -- OUT
14”
20”
IN
OUT
3---3/8”
B
C
A
IN --- OUT
12---3/4”
17”
38
ECOWATER
S Y S T E M S
Dimensions
FIG. 142
Model
Nominal Resin
Tank Size
Salt Storage
Capacity
Dimension
A
Dimension
B
Dimension
C
ESM9CE+ 9” Dia. x 14” 19 kg 41.5 cm 29.1 cm 55 cm
ERM10CE+ 8” Dia. x 25” 25 kg 70 cm 58.4 cm 83.8 cm
ESM11CE+ 8” Dia. x 19” 19 kg 54 cm 41.4 cm 66.8 cm
ESM15CE+ 8” Dia. x 25” 25 kg 70 cm 58.4 cm 83.8 cm
ESM18CE+ 8” Dia. x 35” 100 kg
See figures below
for dimensions.
ERM20CE+ 10” Dia. x 35” 90 kg
ESM25CE+ 10” Dia. x 35” 90 kg
ESM42HTE+ 10” Dia. x 47” 135 kg
Models ESM18CE+, ERM20CE+ &
ESM25CE+
Model ESM42HTE+
Models ESM9CE+, ERM10CE+,
ESM11CE+ & ESM15CE+
50 cm
8.6 cm
35.5
cm
83 cm
115.5
cm
8.6 cm
43.2 cm
32.4
cm
96.5 cm
40.5 cm
40.5
cm
35.5
cm
35.5 cm
93 cm
81 cm
143.8
cm
126.0
cm
OUT
IN
9.5 cm
