EcoWater ESM9CE+ - Page 45

45
ECOWATER
S Y S T E M S
Repair Parts
Ù Included in parts bag
Key
No.
Part No. Description
100 7224087 Screw, #8-32 x 25.4 mm (2 req.)
101 7286039
Repl. Motor
(incl. 2 ea. of Key No. 100)
102 0900857 Screw, #6-20 x 9.5 mm (2 req.)
103 7231385 Motor Plate
104 0503288 Bearing
105 7284964 Cam & Gear
–
7331185
Drain Hose Adaptor Kit
(Models ESM9CE+, ERM10CE+,
ESM11CE+, ESM15CE+ & ESM18CE+)
7332157
Drain Hose Adaptor Kit
(Models ERM20CE+ & ESM25CE+)
106
á
Clip, Drain
107
á
Hose Clamp Ù
108
á
Drain Hose Adaptor
109
á
O-Ring, 15.9 x 20.6 mm
110
á
Flow Plug, 7.6 lpm
(Models ESM9CE+, ERM10CE+,
ESM11CE+, ESM15CE+ & ESM18CE+)
á
Flow Plug, 8.3 lpm
(Models ERM20CE+ & ESM25CE+)
– 7129716 Seal Kit (includes Key Nos. 111-116)
111
á
O-Ring, 11.1 x 15.9 mm
112
á
O-Ring, 19.1 x 23.8 mm
113
á
O-Ring, 85.7 x 92.1 mm
114
á
Repl. Rotor Seal
115
á
O-Ring, 9.5 x 14.3 mm
116
á
Seal, Nozzle & Venturi
117 7082087 Wave Washer
118 7199232 Repl. Rotor & Disc
119 7092642 Plug, Drain Seal
120 7129889 Spring
121 7116713
Clip (2 req.) Ù
122 7170288
O-Ring, 23.8 x 30.2 mm (2 req.) Ù
– 7113040
Turbine & Support Assembly
(includes 1 ea. of Key Nos. 123, 124
& 2 ea. of Key No. 122)
123
á
Turbine Support & Shaft
124
á
Turbine
125 7082053 Valve Body
126 7081201 Retainer, Nozzle & Venturi
127 7170319 O-Ring, 6.4 x 9.5 mm, (2 req.)
128 1202600 Nut-Ferrule
Key
No.
Part No. Description
129
7268421
Nozzle & Venturi Assembly
(Model ESM9CE+)
7187065
Nozzle & Venturi Assembly
(Models ESM11CE+, ERM10CE+,
ESM15 CE+ & ESM18CE+)
7253808
Nozzle & Venturi Assembly
(Models ERM20CE+ & ESM25CE+)
130 7081104 Housing, Nozzle & Venturi
131
7084607
Fill Flow Plug, .57 lpm
(Model ESM9CE+)
1148800
Fill Flow Plug, 1.14 lpm (ERM10CE+,
ESM11CE+, ESM15CE+, ESM18CE+,
ERM20CE+ & ESM25CE+)
132
0521829
Flow Plug, ..38 lpm (Models
ESM9CE+, ERM10CE+, ESM11CE+,
ESM15CE+ & ESM18CE+)
7084607
Flow Plug, .57 gpm
(Models ERM20CE+ & ESM25CE+)
133 7146043 Screen
134 7167659 Screen Support
135 7199729 Cap
–
7298549
Repl. Nozzle, Venturi & Gasket Kit
(Model ESM9CE+)
7290957
Repl. Nozzle, Venturi & Gasket Kit
(Models ESM11CE+, ERM10CE+,
ESM15CE+ & ESM18CE+)
7298913
Repl. Nozzle, Venturi & Gasket Kit
(Models ERM20CE+ & ESM25CE+)
136
á
Cone Screen
137
á
Gasket, Nozzle & Venturi
138
á
Disc, Nozzle & Venturi
139
á
O-Ring, 28.6 x 34.9 mm
140
7311779
Wire Harness, Position Switch
(Models ESM9CE+, ERM10CE+,
ESM11CE+ & ESM15CE+)
7309803
Wire Harness, Position Switch
(Models ESM18CE+, ERM20CE+ &
ESM25CE+)
141 7074123 Screw, #10-14 x 50.8 mm (5 req.)
– 7331266
Valve Cover Assembly
(includes Key Nos. 142 & 143)
142
á
Valve Cover
143
á
Expansion Pin
144 7030713 Switch
145 7325702 Spacer, Motor Mount
146 7070412 Screw, #4-24 x 28.6 mm, flat head
3/4” DC VALVE ASSEMBLY (Models ESM9CE+,
ERM10CE+, ESM11CE+, ESM15CE+, ESM18CE+, ERM20CE+ & ESM25CE+)
