Repair Parts
1” DC VALVE ASSEMBLY (Model ESM42HTE+)
Key
No.
Part No. Description
150 7224087 Screw, #8-32 x 25.4 mm (2 req.)
151 7286039
Repl. Motor
(incl. 2 ea. of Key No. 150)
152 7231393 Motor Plate
153 0900857 Screw, #6-20 x 9.5 mm (3 req.)
154 7171250 Bearing
155 7283489 Cam & Gear
– 7331169
Drain Hose Adaptor Kit
(includes Key Nos. 156-160)
156
á
Clip, Drain
157
á
Hose Clamp Ù
158
á
Drain Hose Adaptor
159
á
O-Ring, 23.8 x 30.2 mm
160
á
Flow Plug, 7.6 lpm
– 7185487 Seal Kit (includes Key Nos. 161-166)
161
á
O-Ring, 15.9 x 20.6 mm
162
á
O-Ring, 28.6 x 38.1 mm
163
á
O-Ring, 114.3 x 123.8 mm
164
á
Repl. Rotor Seal
165
á
Seal
166
á
Seal, Nozzle & Venturi
167 7174313 Bearing, Wave Washer
168 7185500 Repl. Rotor & Disc
169 7171187 Plug, Drain Seal
170 7129889 Spring
171 7089306 Clip (2 req.)
172 7311127
O-Ring, 27.0 x 33.3 mm (2 req.) Ù
Key
No.
Part No. Description
– 7290931
Turbine & Support Assembly
(includes 1 ea. of Key Nos. 173, 174
& 2 ea. of Key No. 172)
173
á
Turbine Support & Shaft
174
á
Turbine
175 7171145 Valve Body
176 7309811 Wire Harness, Position Switch
177 7081201 Retainer, Nozzle & Venturi
178 7170319 O-Ring, 6.4 x 9.5 mm (2 req.)
179 1202600 Nut-Ferrule
180 7253808
Nozzle & Venturi Assembly
(includes Key Nos. 181-190)
181 7081104 Housing, Nozzle & Venturi
182 7095030 Cone Screen
183 1148800 Flow Plug, 1.14 lpm
184 7084607 Flow Plug, .57 lpm
185 7146043 Screen
186 7167659 Screen Support
187 7199729 Cap
– 7298913
Repl. Nozzle, Venturi & Gasket Kit
(includes Key Nos. 188-190)
188
á
Gasket, Nozzle & Venturi
189
á
Disc, Nozzle & Venturi
190
á
O-Ring, 28.6 x 34.9 mm
191 7175199 Wave Washer
192 7171161 Valve Cover
193 7172997 Screw, #10 x 66.7 mm (8 req.)
194 7305150 Switch
195 7140738 Screw, #4-24 x 19.1 mm (2 req.)
Ù Included in parts bag
