ECS Electronics AdvancedIQ AG-6500 - Nitrogen Generator Approvals; Air Compressors

9
Nitrogen Generator Approvals
FM Approved - Standard 1035
UL Listed - 508A Industrial Control Panel
UL-508A Listed to Canadian Standards
CE Certification
Air Compressors
COMP-5-2 Dimensions (Duplex/Horizontal)
84.2"(2,140mm) (L) x 34.6"(878mm) (W) x 48.2"(1,224mm) (H)
COMP-7.5 Dimensions (Simplex/Vertical)
23.6"(1,097mm) (L) x 38.1"(968mm) (W) x 70.1"(1,781mm) (H)
COMP-7.5-2 Dimensions (Duplex/Horizontal)
84.2"(2,140mm) (L) x 34.6"(878mm) (W) x 48.2"(1,224mm) (H)
COMP-10 Dimensions (Simplex/Vertical)
30"(762mm) (L) x 43.2"(1,097mm) (W) x 76.6"(1,946mm) (D)
COMP-10-2 Dimensions (Duplex/Horizontal)
87.5"(2,222mm) (L) x 35.8"(910mm) (W) x 51.5"(1,308mm) (D)
COMP-5-2 Weight (Duplex/Horizontal)
1,265 lbs (574kg)
COMP-7.5 Weight (Simplex/Vertical)
573 lbs (260kg)
COMP-7.5-2 Weight (Duplex/Horizontal)
1,265 lbs (574kg)
COMP-10 Weight (Simplex/Vertical)
800 lbs (362kg)
COMP-10-2 Weight (Duplex/Horizontal)
1,545 lbs (701kg)
COMP-5-2 Power Supply, Two (2) Supplies
460VAC/3 ph/60Hz – 7.6 Amps / 208VAC/3 ph/60Hz – 17.5 Amps (6.3kW)
COMP-7.5 Power Supply
460VAC/3 ph/60Hz - 11 Amps / 208VAC/3 ph/60Hz - 25.3 Amps (8.8kW)
COMP-7.5-2 Power Supply, Two (2) Supplies
460VAC/3 ph/60Hz - 11 Amps / 208VAC/3 ph/60Hz - 25.3 Amps (8.8kW)
COMP-10 Power Supply
460VAC/3 ph/60Hz - 14 Amps / 208VAC/3 ph/60Hz – 32.2 Amps (11.2kW)
COMP-10-2 Power Supply, Two (2) Supplies
460VAC/3 ph/60Hz - 14 Amps / 208VAC/3 ph/60Hz – 32.2 Amps (11.2kW)
COMP-5-2 Air Compressor Output
33 SCFM/2,016 SCFH (951.4 L/min)
COMP-7.5 Air Compressor Output
24 SCFM/1,458 SCFH (688.1 L/min)
COMP-7.5-2 Air Compressor Output
48 SCFM/2,916 SCFH (1,376.2 L/min)
COMP-10 Air Compressor Output
35 SCFM/2,100 SCFH (991.1 L/min)
COMP-10-2 Air Compressor Output
70 SCFM/4,200 SCFH (1,982.2 L/min)
COMP-5 Air Tank Output Connection
½" NPT Female
COMP-7.5 Air Tank Output Connection
½" NPT Female
COMP-10 Air Tank Output Connection
1" NPT Female
Auto-Drain Connection
¼" NPT Female
Auto-Drain Power Supply
120VAC/1 ph/60Hz - Connect to unswitched Power Supply
Temperature Range
40°F - 105°F (5°C - 40°C)
WARRANTY REQUIREMENTS: To ensure warranty of the air compressor by Ingersoll Rand, must adhere
to the following:
1. Use only Ingersoll Rand approved oil (supplied)
2. Install vibration pads under air compressor feet (supplied)
3. Install braided hose directly to isolation valve on air receiver tank (supplied)
