TECHNICAL SPECIFICATIONS
Nitrogen Generators
Dimensions – AG-6500/11000
24.5"(622mm) W x 52.5"(1,334mm) H x 8.5"(216mm) D
Dimensions – AG-18500/22500
24.5"(622mm) W x 76"(1,930mm) H x 12.5"(318mm) D
Dimensions with Bypass Assembly - AG-6500/11000
32.5"(826mm) W x 52.5"(1,334mm) H x 8.5"(216mm) D
Dimensions with Bypass Assembly - AG-18500/22500
32"(813mm) W x 76"(1,930mm) H x 12.5"(318mm) D
Weight - AG-6500/11000
152 lbs (69kg)
Weight - AG-18500/22500
300 lbs (136kg)
Location
Dry Indoor Use
Altitude
Up to 6,560 ft (2,000m)
Temperature Range
40°F - 105°F (5°C - 40°C)
Pollution Degree
2
Nitrogen Generator Cabinet Power Supply
120-240 VAC, 50-60 Hz, 1 ph
Power Consumption
1 Amp
Overvoltage Category
II
AG-6500 Nitrogen Gas Output (COMP-7.5)
4.0 SCFM/240 SCFH (113.3 L/min)
AG-6500 Largest Single Zone Capacity @ 40 psig (2.8 bar)
2,025 gallons (7,666 Liters)
AG-6500 Largest Single Zone Capacity @ 20 psig (1.4 bar)
4,050 gallons (15,331 Liters)
AG-6500 Largest Cumulative System Capacity
6,500 gallons (24,605 Liters)
AG-11000 Nitrogen Gas Output (COMP-7.5)
4.0 SCFM/240 SCFH (113.3 L/min)
AG-11000 Largest Single Zone Capacity @ 40 psig (2.8 bar)
2,025 gallons (7,666 Liters)
AG-11000 Largest Single Zone Capacity @ 20 psig (1.4 bar)
4,050 gallons (15,331 Liters)
AG-11000 Largest Cumulative System Capacity
11,000 gallons (41,640 Liters)
AG-18500 Nitrogen Gas Output (COMP-7.5)
7.1 SCFM/425 SCFH (200.6 L/min)
AG-18500 Largest Single Zone Capacity @ 40 psig (2.8 bar)
2,025 gallons (7,666 Liters)
AG-18500 Largest Single Zone Capacity @ 20 psig (1.4 bar)
4,050 gallons (15,331 Liters)
AG-18500 Largest Cumulative System Capacity
18,500 gallons (70,030 Liters)
AG-22500 Nitrogen Gas Output (COMP-10)
9.2 SCFM/550 SCFH (259.6 L/min)
AG-22500 Largest Single Zone Capacity @ 40 psig (2.8 bar)
2,900 gallons (10,978 Liters)
AG-22500 Largest Single Zone Capacity @ 20 psig (1.4 bar)
5,800 gallons (21,955 Liters)
AG-22500 Largest Cumulative System Capacity
22,500 gallons (85,172 Liters)
Air Inlet Connection
½" NPT Female
Nitrogen/Air Bypass Output Connection
½" NPT Female
Drain Connection
¼" NPT Female
Filter Replacement Part Number
FKSA-FS
Nitrogen Quality
N
2
Purity at Discharge: 98% (maximum of 2.0% oxygen)
N
2
Pressure at Discharge: Min: 15 psig (1 bar); Max: feed air pressure minus 15 psig (1 bar)
N
2
Water Dew Point: Less than -70°F (-57°C)
