GENERATOR CONFIGURATION DIAGRAMS
AG-6500 and AG-11000 Nitrogen Generator Configuration
Flow Meter/Flow
Meter Ball Valve
PLC
Fuses
FILTER #1
5 Micron Coalescing
FILTER #4
.01 Micron Coalescing
FILTER #3
1 Micron Coalescing
Flow Control Valve
Solenoid #1
Excess Air Regulator and
Gauge Assembly
Solenoid #2
Nitrogen Sampling Port
Nitrogen Back Pressure
Regulator and Gauge
On/Off Power Switch
Nitrogen Outlet Valve
Nitrogen Outlet
Generator
Bypass Valve
Air Inlet
Air Inlet Valve
Nitrogen Membrane
System Monitoring
Signal Connections
Power Supply
120-240 VAC
Power Connections
Filter
Depressurization Valve
Air Inlet Y-Strainer
Generator Bypass
Check Valve
Audible Alarm
Permeate Exhaust Gases
DO NOT PLUG
Condensate Drain
FILTER #2
Water Separator
Ethernet
Connection
HMI LCD Display
On Cabinet Door
Excess Air Exhaust
Muffler
Bypass Alarm Sensor
