Air Compressor Dimensions
COMP-7.5 Simplex Air Compressor
COMP-5-2 Duplex Air Compressor COMP-7.5-2 Duplex Air Compressor
COMP-10 Simplex Air Compressor COMP-10-2 Duplex Air Compressor
38.1”
(968mm)
70.1”
(1,781mm)
23.6”
(599mm)
70.1”
(1,781mm)
43.2”
(1,097mm
)
76.6”
(1,946mm)
30”
(762mm)
76.6”
(1,946mm)
34.6”
(878mm)
84.2”
(2,140mm)
48.2”
(1,224mm)
34.6”
(878mm)
84.2”
(2,140mm)
48.2”
(1,224mm)
35.8”
(910mm)
87.5”
(2,222mm)
51.5”
(1,308mm)
