ECS Standard Vent Assembly
ECS Vent Installation Schematic
Gas Sample Port
Float Valve
Y-Strainer
with Ball Valve
In-Line Filter
Connection to
Sprinkler System
Restricted Venting Orifice
Backpressure Regulator
Muffler
½” Quick Connect
Isolation Ball Valve
Nitrogen Supply
ECS Vent
Dry Pipe/Preaction Sprinkler Valve
Fire Sprinkler Riser
1” Outlet Required
