31
Using BIOS
Advanced Chipset Setup
These items define critical timing parameters of the motherboard. You should leave the
items on this page at their default values unless you are very familiar with the technical
specifications of your system hardware. If you change the values incorrectly, you may
introduce fatal errors or recurring instability into your system.
Item Help
CMOS Setup Utility – Copyright (C) 1985-2005, American Megatrends, Inc.
Advanced Chipset Setup
mnlk
CAS Latency Time By SPD
Aperature Size Select 128MB
Share Memory Size 64MB
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F9: Optimized Defaults
CAS Latency Time (By SPD)
When synchronous DRAM is installed, the number fo clock cycles of CAS latency
depends on the DRAM timing. Do not reset this field from the default value specified by
the system designer.
Aperature Size Select (128MB)
This item enables you to select the size of the aperture if you use an AGP graphics
adapter. The AGP aperture refers to a section of the PCI memory address range used for
graphics memory. We recommend that you leave this item at the default value.
Share Memory Size (64MB)
This item shows the VGA memory size borrowed from main memory capability. In this
case, 64MB is borrowed, which in the meanwhile the same the main memory loses.
Options
By SPD
3T
4T
5T
Press <Esc> to return to the main menu page.
