1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the 662/1066T-M2 motherboard. This motherboard is a high
performance, enhanced function motherboard that supports LGA775 socket for latest
Intel® Core
TM
2 Duo/Pentium D/Pentium 4/Celeron D Processors.
The motherboard incorporates the SiS662 Northbridge (NB) and SiS964 Southbridge (SB)
chipsets. The SiS662 Northbridge chipset features the AGTL & AGTL+ compliant bus
driver technology with integrated on-die termination to support Intel Pentium 4 series
processors with FSB 1066 (overclocking)/800/533 MHz. The memory controller supports
DDR2 memory DIMM frequencies of 667/533 and supports two DDR2 Sockets with up to
maximum memory of 2 GB. It can offer bandwidth up to 5.3 GB/s under DDR2 667 to
sustain the bandwidth demand from host processors. High resolution graphics via one PCI
Express slot, intended for Graphics Interface, is fully compliant to the PCI Express Speci-
fication revision 1.1.
The SiS964 Southbridge supports Multiple DMA Bus Architecture with isochroous request
and continuous packet transmission. It supports the build-in USB 2.0 providing higher
bandwith, implementing Universal Serial Bus Specification Revision 2.0 and is compliant
with UHCI 1.1 and EHCI 1.0. It integrates 6-channel AC’97 Audio Codec and provides two
IDE Ultra DMA 133/100/66/33 channel. It supports the Integrated Serial ATA Host Con-
trollers and complies with PCI 2.3 specification at 33 MHz.
There is an advanced full set of I/O ports in the rear panel, including PS/2 mouse and
keyboard connectors, COM1, LPT1, VGA1, four USB ports, one optional LAN port, and
audio jacks for microphone, line-in and line-out. This motherboard is designed in a Micro
ATX factor using a four-layer printed circuit board and measures 244 mm x 220 mm.
1. This motherboard supports native FSB800, and FSB1066 can be
achieved by overclocking. Users please be aware that overclocking
could possibly make the system unstable or damage the system!
2. You must initiate the over-clocking function by adjusting the BIOS
Setup Settings.
