Using BIOS
Integrated Peripherals
These options display items that define the operation of peripheral components on
the system’s input/output ports.
mnlk
Item Help
CMOS Setup Utility – Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F9: Optimized Defaults
DISABLED: disables the
integrated IDE
Controller.
PRIMARY: enables only
the Primary IDE
Controller.
SECONDARY: enables
only the Secondary IDE
Controller.
BOTH: enables both IDE
Controllers.
Onboard IDE Controller
Onboard PCI S-ATA Controller
USB Controller
Legacy USB Support
Onboard AUDIO Function
Modem Device
Onboard LAN Function
OnBoard LAN Boot ROM
Serial Port1 Address
Onboard IR
Parallel Port Address
Parallel Port Mode
ECP Mode DMA Channel
Parallel Port IRQ
Both
IDE
Enabled
Enabled
Enabled
AUTO
Enabled
Disabled
3F8/IRQ4
Disabled
378
ECP
DMA3
IRQ7
Onboard IDE Controller (Both)
Use this item to enable or disable the onboard IDE controllers.
OnBoard PCI S-ATA Controller (IDE)
Use this item to enable or disable the onboard PCI S-ATA channel.
USB Controller (Enabled)
This item enables the USB controller. Leave this at the default “Enabled” if you
want to connect USB devices to your computer.
Legacy USB Support (Enabled)
This item allows users to enable or disable the Legacy USB Support function.
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard audio device.
Modem Device (AUTO)
Use this item to enable or disable the onboard modem device.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the boot function using the onboard LAN boot
rom.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a
port address.
OnBoard IR (Disabled)
Use this item to enable or disable the onboard infrared port, and to assign a port
address.
To Next Page
