Introducing the Motherboard
The motherboard comes with the following expansion options:
Onboard LAN (Optional)
• One PCI Express Lite for Graphic Interface
• Two 32-bit PCI v2.3 compliant slots
• One 40-pin IDE connector that support two IDE devices
• One floppy disk drive interface
• Four 7-pin SATA connectors
Expansion Options
The motherboard supports UDMA bus mastering with transfer rates of 100/66/33 Mb/
s.
• Integrated 10/100/1000 transceiver
• Supports PCI v2.3, 32-bit, 33/66 MHz
• Supports wake-On-LAN (WOL) function and remote wake-up
The onboard LAN controller provides the following features:
The firmware can also be used to set parameters for different processor clock speeds.
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Two PS/2 ports for mouse and keyboard
• One serial port
• One LPT port (optional)
• One VGA port
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in andl line-out
The motherboard has a full set of I/O ports and connectors:
Integrated I/O
• Supports 10/100 Mb/s N-Way Auto negotiation operation
• Half/Full duplex capacity
• Supports wake-On-LAN (WOL) function and remote wake-up
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50 °C.
